342 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
20 :MEASure Commands
:MEASure:DEFine
DELay, <delay
spec>[,<source>] (see
page 356)
:MEASure:DEFine?
DELay[,<source>] (see
page 357)
<delay spec> ::=
<edge_spec1>,<edge_spec2>
edge_spec1 ::=
[<slope>]<occurrence>
edge_spec2 ::=
[<slope>]<occurrence>
<slope> ::= {+ | -}
<occurrence> ::= integer
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
:MEASure:DEFine
THResholds,
<threshold
spec>[,<source>] (see
page 356)
:MEASure:DEFine?
THResholds[,<source>]
(see page 357)
<threshold spec> ::= {STANdard} |
{<threshold mode>,<upper>,
<middle>,<lower>}
<threshold mode> ::= {PERCent |
ABSolute}
<source> ::= {CHANnel<n> |
FUNCtion | MATH | FFT |
WMEMory<r>}
:MEASure:DELay
[<source1>]
[,<source2>] (see
page 359)
:MEASure:DELay?
[<source1>]
[,<source2>] (see
page 359)
<source1,2> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::=
floating-point number delay time
in seconds in NR3 format
:MEASure:DUTYcycle
[<source>] (see
page 361)
:MEASure:DUTYcycle?
[<source>] (see
page 361)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r> |
EXTernal}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= ratio of
positive pulse width to period in
NR3 format
Table 65 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
