Keysight Technologies InfiniiVision DSOX1204G

494 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
24 :SBUS<n> Commands
:SBUS<n>:LIN:TRIGger:
PATTern:DATA <string>
(see page 503)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA? (see
page 503)
<string> ::= "n" where n ::=
32-bit integer in unsigned
decimal when <base> = DECimal
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $} when <base> =
BINary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth
<length> (see
page 505)
:SBUS<n>:LIN:TRIGger:
PATTern:DATA:LENGth?
(see page 505)
<length> ::= integer from 1 to 8
in NR1 format
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat <base>
(see page 506)
:SBUS<n>:LIN:TRIGger:
PATTern:FORMat? (see
page 506)
<base> ::= {BINary | HEX |
DECimal}
Table 72 :SBUS<n>:LIN Commands Summary (continued)
Command Query Options and Query Returns
