Commands Quick Reference 4
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 53
*SAV <value> (see
page 124)
n/a <value> ::= {0 | 1 | 2 | 3 | 4 |
5 | 6 | 7 | 8 | 9}
*SRE <mask> (see
page 125)
*SRE? (see page 126) <mask> ::= sum of all bits that
are set, 0 to 255; an integer in
NR1 format. <mask> ::= following
values:
Bit Weight Name Enables
--- ------ ---- ----------
7 128 OPER Operation Status Reg
6 64 ---- (Not used.)
5 32 ESB Event Status Bit
4 16 MAV Message Available
3 8 ---- (Not used.)
2 4 MSG Message
1 2 USR User
0 1 TRG Trigger
n/a *STB? (see page 127) <value> ::= 0 to 255; an integer
in NR1 format, as shown in the
following:
Bit Weight Name "1" Indicates
--- ------ ---- ---------------
7 128 OPER Operation status
condition occurred.
6 64 RQS/ Instrument is
MSS requesting service.
5 32 ESB Enabled event status
condition occurred.
4 16 MAV Message available.
3 8 ---- (Not used.)
2 4 MSG Message displayed.
1 2 USR User event
condition occurred.
0 1 TRG A trigger occurred.
*TRG (see page 129) n/a n/a
n/a *TST? (see page 130) <result> ::= 0 or non-zero value;
an integer in NR1 format
*WAI (see page 131) n/a n/a
Table 2 Common (*) Commands Summary (continued)
Command Query Options and Query Returns
