Keysight Technologies InfiniiVision DSOX1204G

Commands Quick Reference 4
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 61
:DISPlay:CLEar (see
page 233)
n/a n/a
n/a :DISPlay:DATA?
[<format>][,][<palett
e>] (see page 234)
<format> ::= {BMP | BMP8bit |
PNG}
<palette> ::= {COLor | GRAYscale}
<display data> ::= data in IEEE
488.2 # format
:DISPlay:INTensity:WA
Veform <value> (see
page 235)
:DISPlay:INTensity:WA
Veform? (see page 235)
<value> ::= an integer from 0 to
100 in NR1 format.
:DISPlay:LABel {{0 |
OFF} | {1 | ON}} (see
page 236)
:DISPlay:LABel? (see
page 236)
{0 | 1}
:DISPlay:LABList
<binary block> (see
page 237)
:DISPlay:LABList?
(see page 237)
<binary block> ::= an ordered
list of up to 75 labels, each 10
characters maximum, separated by
newline characters
:DISPlay:PERSistence
<value> (see page 239)
:DISPlay:PERSistence?
(see page 239)
<value> ::= {MINimum | INFinite |
<time>}
<time> ::= seconds in in NR3
format from 100E-3 to 60E0
:DISPlay:VECTors {1 |
ON} (see page 240)
:DISPlay:VECTors?
(see page 240)
1
Table 9 :DISPlay Commands Summary (continued)
Command Query Options and Query Returns
Table 10 :DVM Commands Summary
Command Query Options and Query Returns
:DVM:ARANge {{0 |
OFF} | {1 | ON}} (see
page 242)
:DVM:ARANge? (see
page 242)
{0 | 1}
n/a :DVM:CURRent? (see
page 243)
<dvm_value> ::= floating-point
number in NR3 format
:DVM:ENABle {{0 |
OFF} | {1 | ON}} (see
page 244)
:DVM:ENABle? (see
page 244)
{0 | 1}
n/a :DVM:FREQuency? (see
page 243)
<freq_value> ::= floating-point
number in NR3 format
