634 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
28 :WAVeform Commands
:WAVeform:POINts:MODE
<points_mode> (see
page 647)
:WAVeform:POINts:MODE
? (see page 647)
<points_mode> ::= {NORMal |
MAXimum | RAW}
n/a :WAVeform:PREamble?
(see page 649)
<preamble_block> ::= <format
NR1>, <type NR1>,<points
NR1>,<count NR1>, <xincrement
NR3>, <xorigin NR3>, <xreference
NR1>,<yincrement NR3>, <yorigin
NR3>, <yreference NR1>
<format> ::= an integer in NR1
format:
• 0 for BYTE format
• 1 for WORD format
• 2 for ASCii format
<type> ::= an integer in NR1
format:
• 0 for NORMal type
• 1 for PEAK detect type
• 3 for AVERage type
• 4 for HRESolution type
<count> ::= Average count, or 1
if PEAK detect type or NORMal; an
integer in NR1 format
n/a :WAVeform:SEGMented:C
OUNt? (see page 652)
<count> ::= an integer from 2 to
1000 in NR1 format (with SGM
license)
n/a :WAVeform:SEGMented:T
TAG? (see page 653)
<time_tag> ::= in NR3 format
(with SGM license)
:WAVeform:SOURce
<source> (see
page 654)
:WAVeform:SOURce?
(see page 654)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1 to (# analog channels)
in NR1 format
:WAVeform:SOURce:SUBS
ource <subsource>
(see page 658)
:WAVeform:SOURce:SUBS
ource? (see page 658)
<subsource> ::= {{SUB0 | RX |
MOSI} | {SUB1 | TX | MISO}}
n/a :WAVeform:TYPE? (see
page 659)
<return_mode> ::= {NORM | PEAK |
AVER | HRES}
:WAVeform:UNSigned
{{0 | OFF} | {1 |
ON}} (see page 660)
:WAVeform:UNSigned?
(see page 660)
{0 | 1}
Table 85 :WAVeform Commands Summary (continued)
Command Query Options and Query Returns
