64 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:FRANalysis:FREQuency
:MODE <setting> (see
page 277)
:FRANalysis:FREQuency
:MODE? (see page 277)
<setting> ::= {SWEep | SINGle}
:FRANalysis:FREQuency
:SINGle
<value>[suffix] (see
page 278)
:FRANalysis:FREQuency
:SINGle? (see
page 278)
<value> ::= between 10 Hz and
20 MHz with a resolution of
0.1 Hz in NR3 format
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:FREQuency
:STARt
<value>[suffix] (see
page 279)
:FRANalysis:FREQuency
:STARt? (see page 279)
<value> ::= between 10 Hz and
19.99 MHz with a resolution of
0.1 Hz in NR3 format
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:FREQuency
:STOP <value>[suffix]
(see page 280)
:FRANalysis:FREQuency
:STOP? (see page 280)
<value> ::= between 10.1 Hz and
20 MHz with a resolution of
0.1 Hz in NR3 format
[suffix] ::= {Hz | kHz| MHz}
:FRANalysis:RUN (see
page 281)
n/a n/a
:FRANalysis:SOURce:IN
Put <source> (see
page 282)
:FRANalysis:SOURce:IN
Put? (see page 282)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:FRANalysis:SOURce:OU
TPut <source> (see
page 283)
:FRANalysis:SOURce:OU
TPut? (see page 283)
<source> ::= CHANnel<n>
<n> ::= 1 to (# analog channels)
in NR1 format
:FRANalysis:SWEep:POI
Nts <pts> (see
page 284)
:FRANalysis:SWEep:POI
Nts? (see page 284)
<pts> ::= number of points from 1
to 1000 in NR1 format
:FRANalysis:TRACe
<selection> (see
page 285)
:FRANalysis:TRACe?
(see page 285)
<selection> ::= {NONE | ALL |
GAIN | PHASe}[,{GAIN | PHASe}]
:FRANalysis:WGEN:LOAD
<impedance> (see
page 286)
:FRANalysis:WGEN:LOAD
? (see page 286)
<impedance> ::= {ONEMeg | FIFTy}
:FRANalysis:WGEN:VOLT
age <amplitude> (see
page 287)
:FRANalysis:WGEN:VOLT
age? (see page 287)
<amplitude> ::= amplitude in
volts in NR3 format
Table 13 :FRANalysis Commands Summary (continued)
Command Query Options and Query Returns
