:MEASure:VMAX
[<source>] (see
page 389)
:MEASure:VMAX?
[<source>] (see
page 389)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | FFT |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= maximum
voltage of the selected waveform
in NR3 format
:MEASure:VMIN
[<source>] (see
page 390)
:MEASure:VMIN?
[<source>] (see
page 390)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | FFT |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= minimum
voltage of the selected waveform
in NR3 format
:MEASure:VPP
[<source>] (see
page 391)
:MEASure:VPP?
[<source>] (see
page 391)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | FFT |
WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= voltage
peak-to-peak of the selected
waveform in NR3 format
:MEASure:VRMS
[<interval>][,]
[<type>][,]
[<source>] (see
page 392)
:MEASure:VRMS?
[<interval>][,]
[<type>][,]
[<source>] (see
page 392)
<interval> ::= {CYCLe | DISPlay}
<type> ::= {AC | DC}
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= calculated dc
RMS voltage in NR3 format
Table 17 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
