88 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:UART:FRAMing
<value> (see page 532)
:SBUS<n>:UART:FRAMing
? (see page 532)
<value> ::= {OFF | <decimal> |
<nondecimal>}
<decimal> ::= 8-bit integer from
0-255 (0x00-0xff)
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
:SBUS<n>:UART:PARity
<parity> (see
page 533)
:SBUS<n>:UART:PARity?
(see page 533)
<parity> ::= {EVEN | ODD | NONE}
:SBUS<n>:UART:POLarit
y <polarity> (see
page 534)
:SBUS<n>:UART:POLarit
y? (see page 534)
<polarity> ::= {HIGH | LOW}
:SBUS<n>:UART:SOURce:
RX <source> (see
page 535)
:SBUS<n>:UART:SOURce:
RX? (see page 535)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:UART:SOURce:
TX <source> (see
page 536)
:SBUS<n>:UART:SOURce:
TX? (see page 536)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:UART:TRIGger
:BASE <base> (see
page 537)
:SBUS<n>:UART:TRIGger
:BASE? (see page 537)
<base> ::= {ASCii | HEX}
:SBUS<n>:UART:TRIGger
:BURSt <value> (see
page 538)
:SBUS<n>:UART:TRIGger
:BURSt? (see page 538)
<value> ::= {OFF | 1 to 4096 in
NR1 format}
:SBUS<n>:UART:TRIGger
:DATA <value> (see
page 539)
:SBUS<n>:UART:TRIGger
:DATA? (see page 539)
<value> ::= 8-bit integer from
0-255 (0x00-0xff) in decimal,
<hexadecimal>, <binary>, or
<quoted_string> format
<hexadecimal> ::= #Hnn where n
::= {0,..,9 | A,..,F} for
hexadecimal
<binary> ::= #Bnn...n where n ::=
{0 | 1} for binary
<quoted_string> ::= any of the
128 valid 7-bit ASCII characters
(or standard abbreviations)
Table 26 :SBUS<n>:UART Commands Summary (continued)
Command Query Options and Query Returns
