Table 32 :TRIGger:PATTern Commands Summary
Command Query Options and Query Returns
:TRIGger:PATTern
<string>[,<edge_sourc
e>,<edge>] (see
page 612)
:TRIGger:PATTern?
(see page 612)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | R | F} when <base> =
ASCii
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
when <base> = HEX
<edge_source> ::= {CHANnel<n> |
NONE}
<n> ::= 1 to (# analog channels)
in NR1 format
<edge> ::= {POSitive | NEGative}
:TRIGger:PATTern:FORM
at <base> (see
page 614)
:TRIGger:PATTern:FORM
at? (see page 614)
<base> ::= {ASCii | HEX}
:TRIGger:PATTern:QUAL
ifier <qualifier>
(see page 615)
:TRIGger:PATTern:QUAL
ifier? (see page 615)
<qualifier> ::= ENTered
Table 33 :TRIGger:SHOLd Commands Summary
Command Query Options and Query Returns
:TRIGger:SHOLd:SLOPe
<slope> (see page 617)
:TRIGger:SHOLd:SLOPe?
(see page 617)
<slope> ::= {NEGative | POSitive}
:TRIGger:SHOLd:SOURce
:CLOCk <source> (see
page 618)
:TRIGger:SHOLd:SOURce
:CLOCk? (see page 618)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger:SHOLd:SOURce
:DATA <source> (see
page 619)
:TRIGger:SHOLd:SOURce
:DATA? (see page 619)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:TRIGger:SHOLd:TIME:H
OLD <time>[suffix]
(see page 620)
:TRIGger:SHOLd:TIME:H
OLD? (see page 620)
<time> ::= floating-point number
in NR3 format
[suffix] ::= {s | ms | us | ns |
ps}
:TRIGger:SHOLd:TIME:S
ETup <time>[suffix]
(see page 621)
:TRIGger:SHOLd:TIME:S
ETup? (see page 621)
<time> ::= floating-point number
in NR3 format
[suffix] ::= {s | ms | us | ns |
ps}
