Ricoh Aficio MP C3501 Service Manual

System SP1-xxx
SM Appendix 3-21 D086/D087
Appendix:
SP Mode
Tables
041
Press Reference Temp. *ENG
[0 to 200 / 80 / 1 deg/step]
Specifies the standard temperature for the pressure roller during the heat
storage FB control.
042
Temp. Correction Lower
Limit
*ENG
[-30 to 0 / -2 / 1 deg/step]
Specifies the lower llimit temperature for the heat storage FB control.
043
Temp. Correction Upper
Limit
*ENG
[0 to 30 / 0 / 1 deg/step]
Specifies the upper llimit temperature for the heat storage FB control.
051
Paper Thickness
Coefficient:Plain1
*ENG
[0 to 100 / 20 / 1 /step]
Specifies the additional temperatreu to the heat strage FB control for plain
paper 1.
052
Paper Thickness
Coefficient:Plain2
*ENG
[0 to 100 / 20 / 1 /step]
Specifies the additional temperatreu to the heat strage FB control for plain
paper 2.
1121 [Switch:Rotation Start/Stop]
001
Time:After Reload *ENG
[0 to 100 / 60 / 1 sec/step]
Specifies the ON time of the pressure roler lamp after the fusing temperature
has reached the reload temperature.
002
Time:After Recovery *ENG
[0 to 100 / 15 / 1 sec/step]
Specifies the ON time of the pressure roler lamp after the fusing temperature
has reached the target temperature.
003
Time:After Job *ENG
[0 to 100 / 0 / 1 sec/step]
Specifies the ON time of the pressure roler lamp after the paper feeding has
finished.
004 Press Temp.:After Reload *ENG
[0 to 160 / 160 / 1 deg/step]
