Bit Switches
SM 71 D545
Fax option
Type C5501
D545
System Switch 03 (SP No. 1-101-004)
No Function Comments
0
to
7
Length of time that RDS is
temporarily switched on when
bits 6 and 7 of System Switch
02 are set to "User selectable"
00 - 99 hours (BCD).
This setting is only valid if bits 6 and 7 of
System Switch 02 are set to "User selectable".
The default setting is 24 hours.
System Switch 04 (SP No. 1-101-005)
No Function Comments
0-2 Not used Do not change these settings.
3
Printing dedicated tx
parameters on Quick/Speed
Dial Lists
0: Disabled
1: Enabled
1: Each Quick/Speed dial number on the list is
printed with the dedicated tx parameters (10
bytes each).
The first 10 bytes of data are the programmed
dedicated tx parameters; 34 bytes of data are
printed (the other 24 bytes have no use for
service technicians).
4-7 Not used Do not change these settings.
System Switch 05 - Not used (Do not change the factory settings.)
System Switch 06 (SP No. 1-101-007)
No Function Comments
0 to 7
Margin setting for Create
Margin Transmission
71 to 99 (BCD) %. This setting determines the
reduction ratio when the user uses the Create
Margin Transmission feature.
Default setting: 1001 0011 (93%)
System Switch 07 - Not used (Do not change the factory settings.)
System Switch 08 - Not used (Do not change the factory settings.)
