*RST: WITHin
Parameters for setting and query:
<SearchName> String with the name of the search
Usage: Asynchronous command
SEARch:TRIGger:PATTern:WIDTh[:WIDTh] <SearchName>,<Width>
SEARch:TRIGger:PATTern:WIDTh[:WIDTh]? <SearchName>
For the ranges WITHin and OUTSide, the width defines the center of a range that is
defined by the limits ±delta.
For the ranges SHORter and LONGer, the width defines the maximum and minimum
pulse width, respectively.
To set the range mode, use SEARch:TRIGger:PATTern:WIDTh:RANGe. To set the
delta value, use SEARch:TRIGger:PATTern:WIDTh:DELTa.
Parameters:
<Width> Range: 100E-12 to 864
Increment: 100E-9
*RST: 5E-9
Default unit: s
Parameters for setting and query:
<SearchName> String with the name of the search
Usage: Asynchronous command
SEARch:TRIGger:PATTern:WIDTh:DELTa <SearchName>,<WidthDelta>
SEARch:TRIGger:PATTern:WIDTh:DELTa? <SearchName>
Defines a range around the width value specified using SEARch:TRIGger:PATTern:
WIDTh[:WIDTh].
Parameters:
<WidthDelta> Range: 0 to 432
Increment: 500E-12
*RST: 0
Default unit: s
Parameters for setting and query:
<SearchName> String with the name of the search
Usage: Asynchronous command
18.15.13 State search conditions
SEARch:TRIGger:STATe:CSOurce................................................................................ 1376
SEARch:TRIGger:STATe:CEDGe.................................................................................. 1376
SEARch:TRIGger:STATe:CLEVel...................................................................................1376
SEARch:TRIGger:STATe:A[:ENABle]............................................................................. 1377
