Rohde & Schwarz RTE Series - Configuration Settings for All Serial Protocols

Remote control commands
R&S
®
RTE
1420User Manual 1326.1032.02 ─ 20
18.17.1 Configuration settings for all serial protocols
BUS<m>:TYPE............................................................................................................1420
BUS<m>[:STATe]......................................................................................................... 1420
BUS<m>:SETReflevels.................................................................................................1421
BUS<m>:FAUToset...................................................................................................... 1421
BUS<m>:LABel............................................................................................................1421
BUS<m>:RESult.......................................................................................................... 1421
BUS<m>:THReshold....................................................................................................1421
BUS<m>:RESDetail..................................................................................................... 1422
BUS<m>:FORMat........................................................................................................1422
BUS<m>:NEWList........................................................................................................1422
BUS<m>:SYMBols.......................................................................................................1423
BUS<m>:ZCOupling.....................................................................................................1423
DISPlay:RESultboxes:DEPosition..................................................................................1423
BUS<m>:TYPE <Type>
Defines the bus or protocol type for analysis. The type of available buses depends on
the installed options.
Suffix:
<m>
.
1..4
Selects the serial bus.
Parameters:
<Type> I2C | SPI | UART | CAN | CANFd | LIN | MILS1553 |
MILStd1553 | ARIN429 | ARINc429 | SWIRe | MDIO | HBTO |
USB | USBPD | ETHernet | CMSB | FLXRay | I2S | SENT | CXPI
MILS1553 = MILStd1553: specification MIL-STD-1553
ARIN429 = ARINc429: specification ARINC 429
HBTO: Ethernet 100BASE-T1
CXPI: Clock extension peripheral interface
CMSB: custom decode serial bus
SWIRe: SpaceWire
*RST: I2C
Usage: Asynchronous command
BUS<m>[:STATe] <State>
Enables the decoding of the specified bus.
Suffix:
<m>
.
1..4
Selects the serial bus.
Parameters:
<State> ON | OFF
*RST: OFF
Usage: Asynchronous command
