Siemens SINAMICS G120 - p1466[0...n] CI: Speed controller P-gain scaling; n_ctrl Kp scal; r1468 CO: Speed controller P-gain effective; n_ctr Kp eff; r1469 Speed controller integral time effective; n_ctr Tn eff; p1470[0...n] Speed controller encoderless operation P-gain; n_ctrl SLVC Kp

Parameters
List of Parameters
1-202
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011
Description: Sets the signal source for the scaling of the P gain of the speed controller. This also makes the effective P gain
(including adaptations) scalable.
Description: Displays the effective P gain of the speed controller.
Description: Displays the effective integral time of the speed controller.
Description: Sets the P gain for encoderless operation for the speed controller.
Note: The product p0341 x p0342 is taken into account when automatically calculating the speed controller (p0340 = 1, 3,
4).
Description: Set the integral time for encoderless operation for the speed controller.
Note: The integral component is stopped if the complete controller output or the sum of controller output and torque pre-
control reach the torque limit.
p1466[0...n] CI: Speed controller P-gain scaling / n_ctrl Kp scal
Access level: 4 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: CDS, p0170
Units group: - Unit selection: -
Min Max Factory setting
- - 1
r1468 CO: Speed controller P-gain effective / n_ctr Kp eff
Access level: 4 Calculated: - Data type: FloatingPoint32
Can be changed: - Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- - -
r1469 Speed controller integral time effective / n_ctr Tn eff
Access level: 4 Calculated: - Data type: FloatingPoint32
Can be changed: - Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- [ms] - [ms] - [ms]
p1470[0...n] Speed controller encoderless operation P-gain / n_ctrl SLVC Kp
Access level: 2 Calculated: p0340 = 1,3,4 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Units group: - Unit selection: -
Min Max Factory setting
0.000 999999.000 0.300
p1472[0...n] Speed controller encoderless operation integral time / n_ctrl SLVC Tn
Access level: 2 Calculated: p0340 = 1,3,4 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: DDS, p0180
Units group: - Unit selection: -
Min Max Factory setting
0.0 [ms] 100000.0 [ms] 20.0 [ms]
