Parameters

List of Parameters

1-268

SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011

Description: Connector output to interconnect the status words to a PZD send word.

Index: [0] = Status word 1

[1] = Status word 2

[2] = Free status word 3

[3] = Free status word 4

[4] = Free status word 5

Dependency: Refer to: p2051, p2080, p2081, p2082, p2083

Note: r2089 together with p2080 to p2084 forms five binector-connector converters.

Description: Binector output for bit-serial interconnection of PZD1 (normally control word 1) received from the PROFIdrive con-

troller.

r2089[0...4] CO: Send binector-connector converter status word / Bin/con ZSW send

Access level: 3 Calculated: - Data type: Unsigned16

Can be changed: - Scaling: - Data set: -

Units group: - Unit selection: -

Min Max Factory setting

- - -

Bit field: Bit Signal name 1 signal 0 signal FP

00 Bit 0 ON OFF -

01 Bit 1 ON OFF -

02 Bit 2 ON OFF -

03 Bit 3 ON OFF -

04 Bit 4 ON OFF -

05 Bit 5 ON OFF -

06 Bit 6 ON OFF -

07 Bit 7 ON OFF -

08 Bit 8 ON OFF -

09 Bit 9 ON OFF -

10 Bit 10 ON OFF -

11 Bit 11 ON OFF -

12 Bit 12 ON OFF -

13 Bit 13 ON OFF -

14 Bit 14 ON OFF -

15 Bit 15 ON OFF -

r2090.0...15 BO: PROFIdrive PZD1 receive bit-serial / PZD1 recv bitw
