Parameters

List of Parameters

1-448

SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011

Description: Sets the signal source of input quantity I of instance NOT 5 of the inverter.

Description: Display parameter for the inverted output of instance NOT 5 of the inverter.

Description: Setting parameter for the run-time group in which the instance NOT 5 of the inverter is to be called.

Value: 1: Run-time group 1

2: Run-time group 2

3: Run-time group 3

4: Run-time group 4

5: Run-time group 5

6: Run-time group 6

9999: Do not calculate

Description: Setting parameter for the run sequence of instance NOT 5 within the run-time group set in p20306.

Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run

sequence value.

Description: Sets the signal source of input quantities X0, X1, X2, X3 of instance ADD 2 of the adder.

Index: [0] = Input X0

[1] = Input X1

[2] = Input X2

[3] = Input X3

p20304 BI: NOT 5 input I / NOT 5 input I

Access level: 3 Calculated: - Data type: U32 / Binary

Can be changed: T Scaling: - Data set: -
