1-332

SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011

Description: Displays the ACX file saved in the appropriate directory in the non-volatile memory.

Dependency: Refer to: p0700

Note: For a value = 9999999, the following applies: The read operation is still running.

Description: Displays the ACX file saved in the appropriate directory in the non-volatile memory.

Dependency: Refer to: p1000

Note: For a value = 9999999, the following applies: The read operation is still running.

Description: Displays the ACX file saved in the appropriate directory in the non-volatile memory.

Dependency: Refer to: p1500

Note: For a value = 9999999, the following applies: The read operation is still running.

Description: Displays the macro currently being executed on the drive object.

Dependency: Refer to: p0015, p0700, p1000, p1500, r8570, r8571, r8572, r8573

Description: Selects the storage medium for access via the USB mass storage.

Value: 1: Memory card

2: Flash r/w internal

Note: A change only becomes effective after a POWER ON.

The parameter is not influenced by setting the factory setting.

r8571[0...39] Macro Binector Input (BI) / Macro BI

Access level: 4 Calculated: - Data type: Unsigned32

Can be changed: - Scaling: - Data set: -
