Siemens SINAMICS G120 - Fig. 2-90 6491 - Flux control configuration

Function diagrams Vector control 2-594
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011
Fig. 2-90 6491 – Flux control configuration
- 6491 -
Function diagram
87654321
FP_6491_97_51.vsd
Vector control
G120 CU240B/E-2
13.12.2010 V4.4
Flux control configuration
01
02
00
[6722.5]
[6722.3]
[6723.7]1
0
03
04
05
06 0
07
08
09
10
11
12
13
14
15
Flux control, configuration
Bit No. Meaning
Factory setting
1 = Flux setpoint, soft starting active
1 = Flux setpoint, differentiation active
1 = Quick magnetization
Reserved
Reserved
Reserved
1 = Flux build-up control active
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Flux ctrl config
- ... -
p1401 [D] (0000 0110 bin)
[6723.6]
