List of Parameters
Parameters
1-441
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011
Description: Sets the signal source of input quantity X and of setting value SV of instance INT 0 of the integrator.
Index: [0] = Input X
[1] = Setting value SV
Description: Sets the upper limit value LU of instance INT 0 of the integrator.
Description: Sets the lower limit value LL of instance INT 0 of the integrator.
Description: Sets the integrating time constant Ti in milliseconds of instance INT 0 of the integrator.
Description: Sets the signal source for the "accept setting value" signal of instant INT 0 of the integrator.
Description: Display parameter for output quantity Y of instance INT 0 of the integrator.
If LL>= LU, then the output quantity Y = LU.
p20256[0...1] CI: INT 0 inputs / INT 0 inputs
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- - 0
p20257 INT 0 upper limit value LU / INT 0 upper lim LU
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.0000
p20258 INT 0 lower limit value LL / INT 0 lower lim LL
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
-340.28235E36 340.28235E36 0.0000
p20259 INT 0 integrating time constant in ms / INT 0 T_Integr ms
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
0.00 340.28235E36 0.00
p20260 BI: INT 0 accept setting value S / INT 0 acc set val
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- - 0
r20261 CO: INT 0 output Y / INT 0 output Y
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: - Scaling: PERCENT Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- - -
