Siemens SINAMICS G120 - p20038[0...3] BI: AND 2 inputs; AND 2 inputs; r20039 BO: AND 2 output Q; AND 2 output Q; p20040 AND 2 run-time group; AND 2 RTG; p20041 AND 2 run sequence; AND 2 RunSeq

Parameters
List of Parameters
1-396
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011
Description: Sets the signal source of input quantities I0, I1, I2, I3 of instance AND 2 of the AND function block.
Index: [0] = Input I0
[1] = Input I1
[2] = Input I2
[3] = Input I3
Description: Display parameter for binary quantity Q = I0 & I1 & I2 & I3 of instance AND 2 of the AND function block.
Description: Setting parameter for the run-time group in which the instance AND 2 of the AND function block is to be called.
Value: 1: Run-time group 1
2: Run-time group 2
3: Run-time group 3
4: Run-time group 4
5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance AND 2 within the run-time group set in p20040.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
p20038[0...3] BI: AND 2 inputs / AND 2 inputs
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- - 0
r20039 BO: AND 2 output Q / AND 2 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Can be changed: - Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- - -
p20040 AND 2 run-time group / AND 2 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
1 9999 9999
p20041 AND 2 run sequence / AND 2 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
0 32000 30
