1-415

SINAMICS G120 Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011

Description: Display parameter for quotients Y = X1/X2, integer number quotients YIN, and division remainder MOD = (Y - YIN)

x X2 of instance DIV 1 of the divider.

Index: [0] = Quotient Y

[1] = Integer number quotient YIN

[2] = Div remainder MOD

Description: Display parameter for the signal QF that the divisor X2 of instance DIV 1 of the divider is zero.

X2 = 0.0 => QF = 1

Description: Setting parameter for the run-time group in which instance DIV 1 of the divider is to be called.

Value: 5: Run-time group 5

6: Run-time group 6

9999: Do not calculate

Description: Setting parameter for the run sequence of instance DIV 1 within the run-time group set in p20126.

Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run

sequence value.

Description: Sets the signal source of the input quantity X of instance AVA 0 of the absolute value generator with sign evalua-

tion.

r20124[0...2] CO: DIV 1 quotient / DIV 1 quotient

Access level: 3 Calculated: - Data type: FloatingPoint32

Can be changed: - Scaling: PERCENT Data set: -
