Siemens SINAMICS G120 - Fig. 2-124 7951 - Fixed values, direct selection (p2216 = 1)

Technology controller
Function diagrams
2-631
© Siemens AG 2011 All Rights Reserved SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011
Fig. 2-124 7951 – Fixed values, direct selection (p2216 = 1)
- 7951 -
Function diagram
87654321
FP_7951_97_51.vsd
Technology controller
G120 CU240B/E-2
13.12.2010 V4.4
Fixed values, direct selection (p2216 = 1)
+
++
0 0 0 1
0 0 1 0
1 0 0 0
0 1 0 0
+++
(0)
Tec_ctrl sel bit 0
p2220 [C]
(0)
Tec_ctrl sel bit 1
p2221 [C]
(0)
Tec_ctrl sel bit 2
p2222 [C]
(0)
Tec_ctrl sel bit 3
p2223 [C]
r2224
Tec_ctr FixVal eff [%]
Tec_ctr fix val 1
-200.00 ... 200.00 [%]
p2201 [D] (10.00)
Tec_ctr fix val 2
-200.00 ... 200.00 [%]
p2202 [D] (20.00)
Tec_ctr fix val 3
-200.00 ... 200.00 [%]
p2203 [D] (30.00)
Tec_ctr fix val 4
-200.00 ... 200.00 [%]
p2204 [D] (40.00)
Tec_ctr FixVal ZSW
r2225
r2225
