Parameters
List of Parameters
1-410
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011
Description: Display parameter for the output quantity Y = X0 + X1 + X2 + X3 of instance ADD 1 of the adder.
Description: Setting parameter for the run-time group in which the instance ADD 1 of the adder is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance ADD 1 within the run-time group set in p20100.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source of minuend X1 and subtrahend X2 of instance SUB 0 of the subtractor.
Index: [0] = Minuend X1
[1] = Subtrahend X2
Description: Display parameter for the difference Y = X1 - X2 of instance SUB 0 of the subtractor.
r20099 CO: ADD 1 output Y / ADD 1 output Y
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: - Scaling: PERCENT Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- - -
p20100 ADD 1 run-time group / ADD 1 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
5 9999 9999
p20101 ADD 1 run sequence / ADD 1 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
0 32000 220
p20102[0...1] CI: SUB 0 inputs / SUB 0 inputs
Access level: 3 Calculated: - Data type: U32 / FloatingPoint32
Can be changed: T Scaling: PERCENT Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- - 0
r20103 CO: SUB 0 difference Y / SUB 0 difference Y
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: - Scaling: PERCENT Data set: -
Units group: - Unit selection: -
Min Max Factory setting
- - -
