Parameters
List of Parameters
1-76
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 / Control Units CU240B/E-2 Parameter Manual (LH11), 01/2011
Description: Sets the edge to evaluate the measuring probe signal for speed actual value measurement.
0: 0/1 edge
1: 1/0 edge
Dependency: Refer to: p0580
Description: Sets the number of pulses per revolution (e.g. for disks with holes).
Description: Sets the maximum measuring time for the measuring probe.
If a new pulse is not received before the maximum measuring time has expired, then the speed actual value in
r0586 is set to zero. This timer is re-started with the next pulse.
Dependency: Refer to: r0586
Description: Sets the BERO gear factor.
The measured speed is multiplied by the BERO gear factor and is displayed in r0586.
p0581 Measuring probe, edge / MT edge
CU240E-2
CU240E-2 DP
CU240E-2 DP F
CU240E-2 F
Access level: 3 Calculated: - Data type: Integer16
Can be changed: U, T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
0 1 0
p0582 Measuring probe, pulses per revolution / MT pulses per rev
CU240E-2
CU240E-2 DP
CU240E-2 DP F
CU240E-2 F
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: U, T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
1 12 1
p0583 Measuring probe, maximum measuring time / MT t_meas max
CU240E-2
CU240E-2 DP
CU240E-2 DP F
CU240E-2 F
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
0.040 [s] 10.000 [s] 10.000 [s]
p0585 Measuring probe gear factor / Probe gear factor
CU240E-2
CU240E-2 DP
CU240E-2 DP F
CU240E-2 F
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Data set: -
Units group: - Unit selection: -
Min Max Factory setting
0.00000 1000.00000 1.00000
