Siemens SINUMERIK 828D Turning User Manual

Creating a ShopTurn program
7.18 Example: Standard machining
Turning
264 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
5. Stock removal (roughing)
1. Press the "Cont. turn." and "Stock removal" softkeys.
The "Stock Removal" input window opens.
2. Enter the following technology parameters:
T Roughing tool 80 D1 F 0.350 mm/rev V 400 m/min
3. Enter the following parameters:
Machining Roughing (∇)
Machining direction Longitudinal
Position external
Machining direction
(from front to back)
D 4.000inc
Cutting depth
UX 0.4inc
UZ 0.2inc
DI 0
BL Cylinder
XD 0inc
ZD 0inc
Relief cuts No
Set machining
area limits
No
4. Press the "Accept" softkey.

Siemens SINUMERIK 828D Turning Specifications

General

Control Type	CNC
Application	Turning
Number of Axes	Up to 6
Spindle Control	Yes
Interpolation	Linear, Circular, Helical
Power Supply	24 V DC
PLC	Integrated
Display Size	10.4 inches
Display Type	TFT Color
Interfaces	Ethernet, USB
User Interface	Touchscreen
Processor	Intel
Safety functions	Safe Torque Off (STO)
