Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
537
Parameter Description Unit
Spindle chuck
data
• Only chuck
You enter spindle chuck data in the program.
• Complete
You enter tailstock data in the program.
Note:
Please observe the machine manufacturer’s instructions.
ZC
• The main spindle chuck dimensions - (only for spindle chuck data "yes")
mm
ZS
• Stop dimension of the main spindle - (only for spindle chuck data "yes")
mm
ZE
• Jaw dimension of the main spindle for jaw type 2 - (only for spindle chuck data
"yes")
mm
Counterspindle
Spindle chuck data
• Yes
You enter spindle chuck data in the program.
• No
Spindle chuck data are transferred from the setting data.
Note:
Please observe the machine manufacturer’s instructions.
Spindle chuck data
• Only chuck
You enter spindle chuck data in the program.
• Complete
You enter tailstock data in the program.
Note:
• Please observe the machine manufacturer’s instructions.
Jaw type Selecting the jaw type of the counterspindle. Dimensions of the front edge or stop
edge - (only if spindle chuck data "yes")
• Jaw type 1
• Jaw type 2
ZC The counterspindle chuck dimensions - (only for spindle chuck data "yes") mm
ZS Stop dimension of the counterspindle - (only for spindle chuck data "yes") mm
ZE Jaw dimension of the counterspindle for jaw type 2 - (only for spindle chuck data
"yes")
mm
XR Tailstock diameter - (only for spindle chuck data "complete" and tailstock that has
been set up)
mm
ZR Tailstock length - (only for spindle chuck data "complete" and tailstock that has
been set up)
mm
Mirroring Z
• Yes
Mirroring is used when machining on the Z axis
• No
Mirroring is not used when machining on the Z axis
Work offset Selecting the work offset
