Chapter 2 TL1 Reference
Retrieve RS-422 Output Parameters
Retrieve RS-422 Output Parameters
This command returns the settings for the RS-422 Output module or port specified
by the aid.
Syntax
RTRV-PRMTR-OUT422:[tid]:[aid]:ctag;
Response Format
When the aid specifies a port, the response is:
^^^"aid:mode,bypass,fltmode,pstate,frequency"<cr lf>
where:
aid = port access identifier
mode = 422
bypass = allow Clock C selection: [ON | OFF]
fltmode = [ON | OFF | AUTO] if output is set to Fault if signal levels fall below the
threshold output level
pstate = port enabled state [ON | OFF]
frequency = [0 | 1 |...| 512] where 0 (Reserved) = 4 kHz, 1 = 8 kHz, 2 = 16 kHz ...
512 = 4096 kHz. The resolution of frequency values is 8 kHz.
When the aid specifies a module, the response is:
^^^"aid:mode,bypass,fltmode"<cr lf>
^^^"aid:pstate1,pstate2,...pstate20"<cr lf>
^^^"aid:freq1,freq2,...freq20" <cr lf>
where:
Line 1 contains:
aid = module access identifier
mode = 422
bypass = [ON|OFF] for allowing Clock C selection
fltmode = [ON | OFF | AUTO] if output is set to Fault if signal levels fall below the
threshold output level
Parameter Value Description
[aid] ALL Retrieves the parameters from all RS-422 Output modules
in the shelf.
SxAy[-z] Retrieves parameters from the specified RS-422 Output
module [or port].
To Next Page
