Chapter 6 Alarms and Events
Japan Sine Output Module Alarms and Events
330 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Japan Sine Output Module Alarms and Events
Table 6-32 lists the alarms and events for the Japan Sine Output module, and
includes the typical response for each alarm or event, it’s event number, and a
description or a suggested corrective action. The SNMP MIB trap is listed in the
Alarm/Event/Trap Description column. Table 6-33 lists the default parameters for the
Japan Sine Output module alarms.
Table 6-32. Japan Sine Output Module Alarm and Event Messages
Alarm/
Event/
Trap ID
Typical Alarm/Event/Trap
Response
Description/
Corrective Action
000 Hdw Config, Fault Call Symmetricom Global Services. Return to factory.
001 Configuration, Fault Redundant configuration mismatch. Re-seat or replace module.
002 Clk-A, Fault Clock module in slot A1 is in warm-up mode or has other problems.
003 Clk-B, Fault Clock module in slot A12 is in warm-up mode or has other
problems.
004 Clk-C, Fault Reference signal is in LOS and both clocks have been removed or
are in warm-up.
005 Clk-D, Fault Only in SDU. Loss of backup clock. Check cable.
006 Clk Selected, Fault No clocks, no output.
007 VCXO, Fault VCXO problems, re-seat or replace module.
008 PLL, Fault No clocks or VCXO. Re-seat and check clocks.
009 Redundant, Fault Failed to sync with master module in redundant pair.
010 Squelch, Fault, 40000 PQL is below provisioned value.
011 PortFlt, Fault, 40000 Indicates which output port is in fault (typically shorted). Repair
short and re-enable port.
129 Install, J/SW Output Module Module Installed.
130 Remove, J/SW Output
Module
Module Removed.
131 Enable, J/SW Output
Module, COML
Module Enabled.
132 Disable, J/SW Output
Module, COML
Module Disabled.
133
Restart, in 5 seconds, COML
User request for a module to reboot.
134 Cannot Enable, J/SW
Output Module, COML
Cannot enable module due to configuration error.
194 Port Cntl, Port[1-20],
Enable, COML
User has enabled the specified port.
