Chapter 8 Default Settings
GPS Input Module Default Settings
352 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
GPS Input Module Default Settings
The GPS Input Module maintains factory default and current user configuration
settings. The configuration settings for the GPS Input Module are provided in Table
8-6.
Table 8-6. GPS Input Module Default Configuration Settings
Configuration Setting Factory Default Range
Position (GPS only)
Latitude (+ = North, – = South)
Longitude (+ = East, – = West)
Height
Averages
PDOP
Pos Mode
0
0
0
300
0
Calc
± 90 degrees
±180 degrees
–60 to 4,000 meters
10 to 3600
1 to 10
User | Calc
Min Elevation for position 5 0 to 50 degrees
Min PDOP for position 3 1 to 10
Min Elevation for timing 10 0 to 50 degrees
Module Status Enabled Enabled | Disabled
Priority 0 0 to 10
Sigma limit 25 10 to 1000 US
PQL 2 1 to 16
Disabled SV list Not applicable Up to 31 SV numbers
Min PDOP for position 3 1 to 10
FREQ Set ClkA 16 000 0 to 10 000 000
FREQ Set ClkB 16 000 0 to 10 000 000
FREQ Clear ClkA 12 000 0 to 10 000 000
FREQ Clear ClkB 12 000 0 to 10 000 000
Frequency Alarm Mode Major
Ignore | Report | Minor | Major | Critical
MTIE T10 Set Limit1 260 0 to 60 000
MTIE T10 Set Limit2 325 0 to 60 000
MTIE T100 Set Limit1 440 0 to 60 000
MTIE T100 Set Limit 2 550 0 to 60 000
MTIE T1K Set Limit 1 810 0 to 60 000
MTIE T1K Set Limit 2 1010 0 to 60 000
