Chapter 2 TL1 Reference
Retrieve Output Status
Retrieve Output Status
This command returns the condition (current operating mode and status) of any
Output module or port. This command is not valid for a Line Re-Timing Module.
Syntax
RTRV-STATUS-OUTPUT:[tid]:[aid]:ctag;
Response Format
When the aid specifies a port, the response is:
^^^"aid:mstat,red,clksrc,pql,pstate" <cr lf>
where:
aid = port access identifier
mstat = module status [OK | DIS | FLT]: where OK indicates normal operation,
and DIS or FLT indicate all outputs are turned off
red = redundant [NA | SxAy]: where NA = non-redundant, and the aid = the
redundant module access identifier
clksrc = clock which is generating the output: [CLK-A | CLK-B | CLK-C | CLK-D]
pql = possible Priority Quality Level (SSM) being generated [0 | 1 – 16], where 0
= not applicable and 1 – 16 are valid values
pstate = port status [1 | 0 | F], where 1 = enabled, 0 = disabled, and F= faulted
When the aid specifies a module, the response is:
^^^"aid:mstat,red,clksrc,pql" <cr lf>
^^^"aid:p1,p2,p3,…p20" <cr lf>
where:
The first line contains:
aid = module access identifier
mstat = module status is [OK | DIS | FLT], where OK = normal operation, and
DIS or FLT = all outputs are turned off
red
= [NA | SxAy], where: NA = non-redundant, and SxAy = redundant module
access identifier
clksrc = clock generating the output [CLK-A | CLK-B | CLK-C | CLK-D]
Parameter Value Description
[aid] ALL Retrieves the status parameters from all Output modules
in the shelf.
SxAy[-z] Retrieves the status parameters from the specified
Output module [or port].
To Next Page
