Symmetricom SSU-2000 Technical Reference

12713020-003-2 Revision F.01 – January 2007 SSU-2000 Technical Reference 359
Chapter 8 Default Settings
RS-422 Output Module Default Settings
RS-422 Output Module Default Settings
The factory default setting and range for all RS-422 Output module software
parameters are listed in
Table 8-14 .
Japanese CC Output Module Default Settings
The factory default setting and range for all Japanese Composite Clock Output module
software parameters are listed in
Table 8-15 .
Duty Cycle 5/8 5/8 or 50/50
Alarm Elevation Time 86 400 s 60 to 500 000 s, 0 is disabled
Port Delay 3 (1375 feet) in
Normal mode, 7
(275 feet) in
Subtending mode
0 to 7
(2200, 1925, 1650, 1375, 1100,
825, 550, and 275 feet)
Table 8-14. RS-422 Output Module Configuration
Configuration Setting Factory Default Range
Port State Enabled Disabled/Enabled
Min Clock Acquire Acquire/Lock
Bypass On On/Off
Fault Action On Off/On/Auto
Duty Cycle 50/50 5/8 or 50/50
Alarm Elevation Time 86 400 s 60 to 500 000 s, 0 is disabled
Squelching 0 1 to 16, 0 is disabled
Table 8-15. JCC Output Module Configuration Settings
Configuration Setting Factory Default Range
Port Output (Per Port) Enable Enable | Disable
Bypass Enable Enable | Disable
Table 8-13. Composite Clock Output Module Configuration (Continued)
Configuration Setting Factory Default Range
