Chapter 9 Specifications
Output Signal Specifications
376 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
SDU-2000 Shelf Specifications
Table 9-7 lists the system-level specifications for the SDU-2000.
Table 9-7. SDU-2000 System Specifications
Specification Description
System Specifications
Architecture
2 Buffer modules and 10 mixed Output modules
Expansion drive for up to three additional Expansion shelves
Maximum of four Expansion Shelves per system
Maximum of 61 m (200 ft) between the SSU-2000 main shelf
and the farthest expansion shelf
Output Section
Port
20 ports per Output module pair
Distribution Capacity
100 summed outputs per shelf
Signal Type
DS1
E1
2048 Kbit/s
1 MHz, 1.544 MHz, 2.048 MHz (G703/Sec. 13)
5 MHz
RS-422
Composite Clock (CC)
Japanese CC
Japanese Sine Wave
DS1 Line Re-Timing
E1 Line Re-Timing
Expansion Shelf Mechanical
Height 10.5 in (26.7 cm)
Depth 11.5 in (29.2 cm)
Width 17 in (43.2 cm) without mounting ears
Environmental
Operating Temperature Range 0°C to 50°C
Storage Temperature –20°C to 75°C
Relative Humidity 80% Non-condensing over specified temperature range
Altitude
196 ft (60 m) below sea level to 13123 ft (4000 m) above sea level
