Chapter 6 Alarms and Events
Japan CC Input Module Alarms and Events
312 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Japan CC Input Module Alarms and Events
Table 6-14 lists the alarms and events for the Japan Composite Clock Input module,
and includes the typical response for each alarm or event, it’s event number, and a
description or a suggested corrective action. The SNMP MIB trap is listed in the
Alarm/Event/Trap Description column. Table 6-15 lists the default parameters for the
Japan Composite Clock Input module alarms.
Table 6-14. Japan CC Input Module Alarm and Event Messages
Alarm/
Event/
Trap ID
Typical Alarm/Event/Trap
Response
Description/
Corrective Action
000 LOS, Fault No input signal. Verify signal is connected. To extinguish alarm,
disable port.
003 BPV, Fault Invalid BPV density.
005 Hdw Config, Fault Input module can be installed only in the Main shelf.
If module is installed in slot previously used by a different module
type, use the CONF xAy REMOVE command.
If problem persists, call Symmetricom Global Services
006 Clk PLL, Fault One of the clock PLLs is not locked, Check clock. Re-seat module.
007 Phase Hdw, Fault The phase measurements are invalid or missing. Re-seat module.
008 Phase 3Sigma, Fault Check incoming signal quality.
The phase measurements are invalid or missing.
009 4kHz Alignment, Fault The unselected Japan Composite Clock input phase polarity is
different from the selected JCC input reference.
010 400Hz Alignment, Fault The unselected Japan Composite Clock input phase polarity is
different from the selected JCC input reference.
129 Install, J/CC Input Module The Input module has been installed.
130 Remove, J/CC Input Module The Input module has been removed.
131 Enable, J/CC Input Module,
COML
The Input module has been enabled.
132 Disable, J/CC Input Module,
COML
The Input module has been disabled.
133
Restart, in 5 seconds, COML Module re-boot.
134 Cannot Enable, J/CC Input
Module, COML
Cannot enable module due to configuration error.
144 Zero Phase, B, COML User has forced the phase to be cleared.
148 Operating Mode, Japan
Subtending
User has set operating mode.
199 Port, Disable, COML User has disabled the input.
200 400Hz, On, COML User has enabled 400 Hz sync.
