Chapter 8 Default Settings
Japanese Sine Wave Input Module Default Settings
354 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Japanese Sine Wave Input Module Default Settings
The Japanese Sine Wave Input module maintains factory default and current user
configuration information in nonvolatile memory. This information is retrieved at
power up and is modified by commands from the Communications module. The
factory configuration settings for the JSW Input module are shown in Table 8-8.
Table 8-8. Japanese Sine Wave Input Module Configuration Settings
Configuration Setting Factory Default Range
Input Frequency
(for unframed signals)
6.312 MHz 1.544 MHz | 6.312 MHz
Provisioned PQL 4 1–16
Priority 1 0–10 (0 = Monitor)
FREQ Set ClkA 16 000 0 to 10 000 000
FREQ Set ClkB 16 000 0 to 10 000 000
FREQ Clear ClkA 12 000 0 to 10 000 000
FREQ Clear ClkB 12 000 0 to 10 000 000
Frequency Alarm Mode Major
Ignore | Report | Minor | Major | Critical
MTIE T10 Set Limit1 260 0 to 60 000
MTIE T10 Set Limit2 325 0 to 60 000
MTIE T100 Set Limit1 440 0 to 60 000
MTIE T100 Set Limit 2 550 0 to 60 000
MTIE T1K Set Limit 1 810 0 to 60 000
MTIE T1K Set Limit 2 1010 0 to 60 000
MTIE T10K Set Limit 1 880 0 to 60 000
MTIE T10K Set Limit 2 1100 0 to 60 000
MTIE T100K Set Limit 1 1600 0 to 60 000
MTIE T100K Set Limit 2 2000 0 to 60 000
MTIE T10 Clear Limit 1 230 0 to 60 000
MTIE T10 Clear Limit 2 290 0 to 60 000
MTIE T100 Clear Limit 1 400 0 to 60 000
MTIE T100 Clear Limit 2 490 0 to 60 000
MTIE T1K Clear Limit 1 730 0 to 60 000
MTIE T1K Clear Limit 2 910 0 to 60 000
