Symmetricom SSU-2000 Technical Reference

Chapter 6 Alarms and Events
RS-422 Output Module Alarms and Events
332 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
RS-422 Output Module Alarms and Events
Table 6-34 lists the alarms and events for the RS-422 Output module, and includes
the typical response for each alarm or event, it’s event number, and a description or
a suggested corrective action. The SNMP MIB trap is listed in the Alarm/Event/Trap
Description column. Table 6-35 lists the default parameters for the RS-422 Output
module alarms.
Table 6-34. RS-422 Output Module Alarm and Event Messages
Alarm/
Event/
Trap ID
Typical Alarm/Event/Trap
Response
Description/
Corrective Action
000 Hdw Config, Fault If module is installed in slot previously used by a different module
type, use the CONF xAy REMOVE command.
If problem persists, call Symmetricom Global Services
001 Configuration, Fault Redundant configuration mismatch. Re-seat or replace module.
002 Clk-A, Lost Clock module in slot A1 is in warm-up mode or has other problems.
003 Clk-B, Lost Clock module in slot A12 is in warm-up mode or has other
problems.
004 Clk-C, Lost Reference signal is in LOS and both clocks have been removed or
are in warm-up.
005 Clk-D, Lost Only in SDU. Loss of backup clock. Check cable.
006 Clk Selected, None No clocks, no output.
007 VCXO, Lost VCXO problems, re-seat or replace module.
008 PLL, Unlocked No clocks or VCXO. Re-seat and check clocks.
009 PortFlt, Fault, 40000 Indicates which output port is in fault (typically shorted). Repair
short and re-enable port.
129 Install, RS422 Output
Module
Module Installed.
130 Remove, RS422 Output
Module
Module Removed.
131 Enable, RS422 Output
Module, COML
Module Enabled.
132 Disable, RS422 Output
Module, COML
Module Disabled.
133
Restart, in 5 seconds, COML User request for a module to reboot.
134 Cannot Enable, RS422
Output Module, COML
Cannot enable module due to configuration error.
203 Bypass, On, COML User has changed the Bypass mode.
205 Frequency, Port[1-4], 16kHz,
COML
User has changed the port output frequency.
