Chapter 5 Antennas
Antenna Kits and Accessories
276 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
GPS L1 Inline Amplifier Assembly
This assembly (item number 11013077-000-0) mounted on an aluminum plate is
designed with mounting holes to allow for several mounting configurations. The
assembly consists of a GPS inline amplifier, a 90 V L1 Transient Eliminator, and an
adapter for connectivity.
Antenna Coaxial Cables
Symmetricom provides several low-loss cable types, as well as LMR-400 with
N-type connectors on both ends.
Table 5-8 lists the optional antenna coaxial cables
Table 5-9 lists the optional antenna coaxial cable crimper kits
Table 5-10 provides antenna cable specifications
Table 5-8. Optional Antenna Coaxial Cables
Part Number Description
12012992-xxx-0 Cable, RG-213/U, with N-Type Connectors
12012994-xxx-0 Cable, UHF/VHF (B-89913), with N-Type Connectors
12012995-xxx-0 Cable, UHF/VHF (B-9913), with N-Type Connectors
12013076-xxx-0 Cable, LMR-400 or equivalent, with N-Type Connectors
Contact your sales office for available cable lengths and specific cable item number.
Table 5-9. Optional Antenna Coaxial Cable Crimper Kits
Part Number Description
12813059-000-0 Crimp Kit for RG213 (10 each N-Type Connectors, crimp tool,
weatherproof tape)
12813060-000-0 Crimp Kit for 9913 (10 each N-Type Connectors, crimp tool,
weatherproof tape)
12813080-000-0 Crimp Kit for LMR-400 or equivalent (10 ea. N-Type connector,
crimp tool, weatherproof tape)
