Chapter 2 TL1 Reference
Retrieve E1/2048 kHz Output Parameters
60 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Retrieve E1/2048 kHz Output Parameters
This command returns the settings for the E1/2048 kHz Output module or port
designated by the aid.
Syntax
RTRV-PRMTR-OUTE12048:[tid]:[aid]:ctag;
Response Format
When the aid specifies a port, the format for each line is:
^^^"aid:mode,bypass,zs,signal,pstate,squelch,crc,ssm,bit"<cr lf>
where:
aid = port access identifier
mode = multiframe selection [CAS | CCS]
bypass = allow Clock C selection: [ON | OFF]
zs = zero suppression [ON | OFF]
signal = port signal type [ E1 | 2048]
pstate = port state [ON | OFF]
squelch = threshold value [0 | 1 – 16] (where 0 = disabled). If the reference clock
PQL exceeds this value, then the output is turned off.
crc = error checking [ON | OFF]
ssm = Sync Status Messaging enabled [ON | OFF]
bit = bit number [ 4 – 8] of the Time Slot 0 word used for the E1 sync status
message
When the aid specfies a module, then the response is four lines as follows:
^^^"aid: mode,bypass,zs,crc,ssm,bit"<cr lf>
^^^"aid:signal1,signal2,signal3,…signal20"<cr lf>
^^^"aid:pstate1,pstate2,pstate3,…pstate20"<cr lf>
^^^"aid:squelch1,squelch2,squelch3,…squelch20"<cr lf>
Parameter Value Description
[aid] ALL Retrieves the parameters from all E1/2048 kHz Output
modules in the shelf.
SxAy[-z] Retrieves parameters from the specified E1/2048 kHz
Output module [or port].
