12713020-003-2 Revision F.01 – January 2007 SSU-2000 Technical Reference 353
Chapter 8 Default Settings
Japanese CC Input Module Default Settings
Japanese CC Input Module Default Settings
The Japanese Composite Clock Input module maintains factory default and current
user configuration information in nonvolatile memory. This information is retrieved at
power up and is modified by commands from the Communications module. The
factory configuration settings for the JCC Input module are shown in Table 8-7.
MTIE T10K Set Limit 1 880 0 to 60 000
MTIE T10K Set Limit 2 1100 0 to 60 000
MTIE T100K Set Limit 1 1600 0 to 60 000
MTIE T100K Set Limit 2 2000 0 to 60 000
MTIE T10 Clear Limit 1 230 0 to 60 000
MTIE T10 Clear Limit 2 290 0 to 60 000
MTIE T100 Clear Limit 1 400 0 to 60 000
MTIE T100 Clear Limit 2 490 0 to 60 000
MTIE T1K Clear Limit 1 730 0 to 60 000
MTIE T1K Clear Limit 2 9910 0 to 60 000
MTIE T10K Clear Limit 1 790 0 to 60 000
MTIE T10K Clear Limit 2 990 0 to 60 000
MTIE T100K Clear Limit 1 1440 0 to 60 000
MTIE T100K Clear Limit 2 1800 0 to 60 000
Table 8-7. Japanese Composite Clock Input Module Configuration Settings
Configuration Setting Factory Default Range
400 Hz ON ON | OFF
Provisioned PQL 4 1 to 16
Priority 1 1 to 10 (0 = Monitor)
Alarm Set Delay 0 seconds 0 to 172 800 seconds
Alarm Elevation Time 86 400 seconds 60 to 500 000 seconds, 0 is disabled
Port Status Enabled Enabled | Disabled
Port Name None (blank) Any string from 0 – 20 characters
Table 8-6. GPS Input Module Default Configuration (Continued)Settings
Configuration Setting Factory Default Range
