Chapter 2 TL1 Reference
TL1 Command and Response Conventions
30 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Autonomous Report Conventions
The SSU-2000 sends autonomous reports in response to a detected alarm
condition or status change. You can select one of two formats for autonomous
messages: GR-831 or GR-833. Use the RTRV-PRMTR-TL1FORMAT command to
select which format is generated. These reports are similar to the RTRV-ALARM
command responses, but contain an alarm code rather than the complied line.
The GR-831 format for an autonomous alarm report is:
<cr lf lf>
^^^sid^date^time <cr lf>
alrmcde^atag^REPT^ALM^[AIDTYPE]<cr lf>
^^^"aid:ntfcncde,condtype,srveff,ocrdat,ocrtm:condscr"<cr lf>
The GR-831 format for an autonomous event report is:
<cr lf lf>
^^^sid^date^time <cr lf>
alrmcde^atag^REPT^EVT<cr lf>
^^^"aid:ntfcncde,condtype,srveff,ocrdat,ocrtm:condscr"<cr lf>
where:
sid is the source ID, and is the assigned name of the unit sending the message
date is the current date in the format: YY-MM-DD
time is the current timestamp information in the 24-hour format HH:MM:SS
alrmcde (Alarm Code) indicates the severity level of the reported alarm or event.
The alarm code is one of these four two-character codes:
Table 2-1. Denied Response Error Codes
Error Code Definition
ICNV Command Not Valid
IIAC Invalid aid Code
IICT Invalid ctag
IITA Invalid Target Identifier
IPEX Extra Parameter
IPMS Parameter Missing
IPNV Parameter Not Valid
SDNR Data Not Ready
