Chapter 2 TL1 Reference
Set Japan Sine Output Parameters
154 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Set Japan Sine Output Parameters
This command sets the parameters for the specified Japan Sine Output module or
port.
Syntax
SET-PRMTR-OUTSINE:[tid]:[aid]:ctag::[pstate],[bypass],[frequency],
[squelch];
Empty fields leave parameters unchanged.
Related Commands
Retrieve Japan Sine Output Parameters, on page 79
Parameter Format Description
aid S1Ay[-z] Sets the parameters for the specfied Japan Sine Output
module [or port].
pstate ON | OFF Enables or disables the specified module [or port].
bypass ON | OFF Allows operation when Clock C is the active clock.
frequency 1.544 |
6.312
Sets the output frequency (in MHz) of the specified
module [or port].
squelch 0 | 1 - 16 Turns off the specified port if the reference clock PQL
exceeds the squelch threshold specified in this field. 0
disables the function.
To Next Page
