Chapter 2 TL1 Reference
Retrieve DS1/E1 Output Parameters
52 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Retrieve DS1/E1 Output Parameters
This command returns the DS1 or E1 Output module or port settings specified by
the aid.
Syntax
RTRV-PRMTR-OUTPUT:[tid]:[aid]:ctag;
Response Format
When the aid specifies a port, the response is:
^^^"aid:mode,level,bypass,zs,crc,bit,pstate,len" <cr lf>
where:
aid = port access identifier
mode = output signal mode [ESF | D4 | CCS | CAS]
level = minimum clock level to enable outputs on the module [ACQ | LOCK]
bypass = allow Clock C selection [ON | OFF]
zs = zero suppression [ON | OFF]
crc = error checking [ON | OFF]
bit = SSM bit [4 – 8] for E1 sync status messages
pstate = port enabled state [ON | OFF]
len = line length setting in feet [133 | 266 | 399 | 533 | 655] for DS1 outputs
When the aid specifies a module, the response is:
^^^"aid:mode,level,bypass,zs,crc,bit" <cr lf>
^^^"aid:pstate1,pstate2,…pstate20" <cr lf>
^^^"aid:len1,len2,len3,…,len20" <cr lf>
where:
Line 1 contains:
aid = module access identifier
mode = outputs signal mode: [ESF | D4 | CCS | CAS]
level = minimum clock level to enable outputs on the module [ACQ | LOCK]
Parameter Value Description
[aid] ALL Retrieves the parameters from all DS1 or E1 Output
modules in the shelf.
SxAy[-z] Retrieves parameters from the specified DS1 or E1
Output module [or port].
