Chapter 2 TL1 Reference
Retrieve CC Output Parameters
44 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Retrieve CC Output Parameters
This command returns the settings for the Composite Clock Output module and port
designated by the aid.
Syntax
RTRV-PRMTR-CCOUT:[tid]:[aid]:ctag;
Response Format
When the aid specifies a port, the format for each response message line is:
^^^"aid:mode,level,bypass,pstate,duty,pcomp"<cr lf>
where:
aid = port access identifier
mode = CC (composite clock)
level = minimum clock level to enable outputs on the module [WARM | ACQ |
LOCK]
bypass = allow Clock C selection: [ON | OFF]
pstate = port state [ON | OFF]
duty = duty cycle of the modules outputs [1 | 0] where 1 = 5/8 and 0 = 50/50
pcomp = phase compensation [1 – 7] where 7 = no compensation and 0 = 2200 ft.
The resolution is 275 ft.
When the aid specifies a module, then the response is four lines as follows:
^^^"aid: mode,level,bypass"<cr lf>
^^^"aid:pstate1,pstate2,pstate3,…pstate20"<cr lf>
^^^"aid:duty1,duty2,duty3,…duty20"<cr lf>
^^^"aid:pcomp1,pcomp2,pcomp3,…,pcomp20"<cr lf>
Line 1 contains:
aid = module access identifier
mode = CC
level = minimum clock level to enable outputs on the module [WARM | ACQ |
LOCK]
bypass = allow Clock C selection: [ON | OFF]
Parameter Value Description
[aid] ALL Retrieves the parameters from all CC Output modules in
the shelf.
SxAy[-z] Retrieves parameters from the specified CC Output
module [or port].
