12713020-003-2 Revision F.01 – January 2007 SSU-2000 Technical Reference 55
Chapter 2 TL1 Reference
Retrieve DS1 LRM Status
Retrieve DS1 LRM Status
This command returns the condition (current operating mode and status) of the
specified DS1 Line Re-Timing Module or port.
Syntax
RTRV-STATUS-LRM:[tid]:[aid]:ctag;
Response Format
^^^"aid:mstat,clksrc,ctaid" <cr lf>
^^^"aid:pstat,frame,los,ais,lof,bpv,slip,slipcount,los_side2" <cr lf>
where:
Line 1 contains:
aid = module or port access identifier
mstat = module status [ENA | DIS]
clksrc = the reference clock [A | B | C | D | NONE | PLLFLT]
ctaid = the Cut-Through Assembly (CTA) [NONE | DUAL | QUAD | UNK];
where: NONE = no CTA installed, DUAL = Dual (2 Port) CTA is installed, QUAD =
Quad (4 Port) CTA is installed, UNK = unknown
Line 2 contains:
aid = module or port access identifier
pstat = [OK | CUT | DIS] for port status; where OK = port is enabled and
functioning correctly, CUT = port is in cut-through mode, DIS = port is disabled
and not in cut-through mode
frame = [D4 | ESF | NONE]
los, ais, lof, bpv, and slip = the current-second error condition [F | OK] where
F indicates an error has occurred
slipcount = number of slips in a 24-hour period
los_side2 (the LOS of Side 2) is [F | OK] where F indicates an error occurred.
Related Commands
Set DS1 LRM Parameters, on page 144
Parameter Value Description
[aid] ALL Retrieves the status parameters from all DS1 LRMs.
SxAy[-z] Retrieves the status parameters from the specified DS1
LRM [or port].
