Chapter 6 Alarms and Events
GPS Input Module Alarms and Events
310 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
132
Disable, GPS Module, COML
The Input module has been disabled.
133
Restart, in 5 seconds, COML
Module re-boot.
134 Cannot Enable, GPS
Module, COML
Internal firmware conflict. Restart module; if the problem persists,
call SGS.
144 Zero Phase, B, COML User has forced the phase to be cleared.
193 Priority, 3, COML User has changed the Priority level on the GPS input module to the
level shown.
194 Prov PQL, 2, COML User has changed the Priority quality level to the level shown.
195 ElMask, POS 10, COML User has changed the elevation mask on the input module to the
level shown.
197 Satellite Ignore, 3, COML User has set the GPS engine to ignore the satellite number
indicated.
198
Position, 300 AvgCnt, COML
The position has been calculated.
199 Tracking Mode, On, COML User specified GPS positioning mode has been set.
200 Pos Set by Rec, Information
Locked, COML
User specified GPS positioning mode has been set to Calc and the
position has been recalculated and locked in.
201 Engine Set Time, GPS System time has been set to UTC by the GPS module.
203 PDOP, 2, COML User has changed the PDOP on the GPS input module to the
setting shown.
224 IoName, Set A user has set the IO Name.
251
Err Delay, (0), 10 sec, COML
An alarm delay time change.
252 Alm Level, (2), Maj, COML An alarm level change.
253 Elevate Time 86400 sec,
COML
An alarm elevation time change.
254 Setup, Save, COML User defaults have been set and saved.
Table 6-13. GPS Input Module Alarm Defaults
ID Description Alarm Level
000 Hdw Config Major
001 Tracking Major
002 Antna Conntd Major
003 Antna Shorted Major
Table 6-12. GPS Input Module Alarm and Event Messages (Continued)
Alarm/
Event/
Trap ID
Typical Alarm/Event/Trap
Response
Description/
Corrective Action
To Next Page
