12713020-003-2 Revision F.01 – January 2007 SSU-2000 Technical Reference 167
Chapter 2 TL1 Reference
Set RS-422 Output Parameters
Set RS-422 Output Parameters
This command sets the output parameters for the specified RS-422 Output module
or port. You set the frequency for ports 1 through 10; port 11 automatically takes the
frequency of port 1, port 12 automatically takes the frequency of port 2, and so on
through port 20.
Syntax
SET-PRMTR-OUT422:[tid]:[aid]:ctag::[pstate],[bypass],[fltmode],
[frequency];
Empty fields leave parameters unchanged.
Related Commands
Retrieve RS-422 Output Parameters, on page 109
Parameter Format Description
aid SxAy[-z] Sets the parameters for the specfied RS-422 Output .
pstate ON | OFF Enables or disables the specified module [or port].
bypass ON | OFF Allows operation when Clock C is the active clock.
fltmode ON | OFF |
AUTO
Turns the output of the specified module [or port] on or off
when the output level exceeds the 2.1 V fault threshold.
frequency 1 - 512
Sets the frequency for the specified
module [or port]
,
where 1 = 8 kHz, 2 = 16 kHz ... 512 = 4096 kHz. The
resolution is 8 kHz per step.
