Chapter 2 TL1 Reference
Retrieve 2048 kHz Clock Output Parameters
34 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Retrieve 2048 kHz Clock Output Parameters
This command returns the settings for the 2048 kHz Output module or port
designated by the aid.
Syntax
RTRV-PRMTR-CLKOUT:[tid]:[aid]:ctag;
Response Format
When the aid specifies a port, the response is:
^^^"aid:mode,level,bypass,fltmode,pstate,squelch" <cr lf>
where:
aid = port access identifier
mode = CLK
level = minimum clock level to enable outputs on the module [ACQ | LOCK]
bypass = allow Clock C selection: [ON | OFF]
fltmode = determines if outputs are set to Fault [OFF | ON | AUTO] when signal
levels drop below the threshold output level
pstate = port state [1 | 0] (where 1 = ON and 0 = OFF)
squelch = threshold value [0 | 1 – 16] (where 0 = disabled). If the reference clock
PQL exceeds this value, then the output is turned off
When the aid specifies a module, the response is:
^^^"aid:mode,level,bypass,fltmode" <cr lf>
^^^"aid:pstate1,pstate2,…,pstate20" <cr lf>
^^^"aid:squelch1,squelch2,…,squelch20" <cr lf>
Line 1 contains:
aid = module access identifier
mode = CLK
level = minimum clock level to enable outputs on the module [ACQ | LOCK]
bypass = [ON | OFF] for allowing Clock C selection
Parameter Value Description
[aid] ALL Retrieves the parameters from all 2048 kHz Output
modules in the shelf.
SxAy[-z] Retrieves parameters from the specified 2048 kHz Output
module [or port].
