Chapter 2 TL1 Reference
Set CC Output Parameters
136 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Set CC Output Parameters
This command sets the parameters on the specified Composite Clock Output
module or port.
Syntax
SET-PRMTR-CCOUT:[tid]:[aid]:ctag::[pstate],[mode],[level],[bypass],
[duty],[pcomp];
Empty fields leave parameters unchanged.
Related Commands
Retrieve CC Output Parameters, on page 44
Parameter Format Description
aid SxAy[-z] Sets the parameters for the specfied CC Output module
[or port].
pstate ON | OFF Turns the specified module [or port] on or off.
mode This parameter is ignored.
level ACQ | LOCK Outputs are turned on when the active Clock module is at
or above the specified state.
bypass ON | OFF Allows operation when Clock C is the active clock.
duty 1 | 0 Sets the duty cycle on the specified module [or port] to
5/8 (1) or 50/50 (0).
pcomp 0 - 7 Sets the phase compensation delay on the specified
module [or port], where 0 = No compensation and 8 =
2200 ft. The resolution of pcomp values is 275 ft.
