Chapter 2 TL1 Reference
Set DS1/E1 Input Parameters
142 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
Set DS1/E1 Input Parameters
This command sets the parameters for the specified DS1 or E1 Input module or
port.
Syntax
SET-PRMTR-INPUT:[tid]:[aid]:ctag::[pstate],[pri],[pql],[mode],[ssm],
[zs],[crc],[gain],[csflt],[bit];
Empty fields leave parameters unchanged.
Related Commands
Retrieve DS1/E1 Input Parameters, on page 51
Parameter Format Description
aid S1Ay[-z] Sets the parameters for the specfied DS1 or E1 Input
module [or port].
pstate ON | OFF Turns the specified module [or port] on or off.
pri 1 - 10 |
MON
Sets the Priority for the specified module [or port]; MON =
Monitor.
pql 1 - 16 Sets the Priority Quality Level for the specified module [or
port].
mode ESF | D4 |
CCS |CAS |
1 | 1.544
| 2.048 |
5 | 10
Sets the framing mode or clock frequency in MHz. A
DENY with ICNV message is returned if the mode setting
does not match the module type (DS1 or E1).
If mode is set to a framed type then frequency is set to
correct frequency for type DS1 (1.544) or E1 (2.048).
ssm ON | OFF Sets the specified module [or port] to read or ignore
incoming Sync Status Messages.
zs ON | OFF Enables or disables zero suppression
For DS1: On = B8ZS, Off = AMI
For E1: On = HDB3, Off = AMI
crc ON | OFF Enables or disables error checking.
gain ON | OFF When set to ON, 20 dB gain is applied to the input signal.
SSM, zs, crc, and gain are ignored for clock modes.
csflt HI | LO |
OFF
Sets the external Cesium fault alarm input.
bit 4 - 8 Sets the bit number of the Time Slot 0 word used for the
E1 SSM. For DS1 input, the bit value is ignored.
