Chapter 6 Alarms and Events
2048 kHz Output Module Alarms and Events
320 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
2048 kHz Output Module Alarms and Events
Table 6-22 lists the alarms and events for the 2048 kHz Output module, and
includes the typical response for each alarm or event, it’s event number, and a
description or a suggested corrective action. The SNMP MIB trap is listed in the
Alarm/Event/Trap Description column. Table 6-23 lists the default parameters for the
2048 kHz Output module alarms.
Table 6-22. 2048 kHz Output Module Alarm and Event Messages
Alarm/
Event/
Trap ID
Typical Alarm/Event/Trap
Response
Description/
Corrective Action
000 Alarm Deprecated, Fault Alarm not enabled
001 Module Match, Invalid A redundant pair has one DS1 module and one E1 module.
Replace module.
002 Clk-A, Lost Clock module in slot A1 is in warm-up mode or has other problems.
003 Clk-B, Lost Clock module in slot A12 is in warm-up mode or has other
problems.
004 Clk-C, Lost Reference signal is in LOS and both clocks have been removed or
are in warm-up.
005 Clk-D, Lost Only in SDU. Loss of backup clock. Check cable.
006 Clk Level, Below Clock A or B is below output module setting.
007 Clk Selected, None No clocks, no output.
008 VCXO, Lost VCXO problems, re-seat or replace module.
009 PLL, Unlocked No clocks or VCXO. Re-seat and check clocks.
010 Configuration, Fault Redundant configuration mismatch. Re-seat or replace module.
011 IntPortFlt, Active, 40000 Driver chip indicated a port fault on port 2 (4000 Hex).
013 Hdw Config, Fault If module is installed in slot previously used by a different module
type, use the CONF xAy REMOVE command.
If problem persists, call Symmetricom Global Services
014 Squelch, Below Prov Input signal PQL is below user-defined threshold.
129 Install, 2048 Output Module Module Installed
130 Remove, 2048 Output
Module
Module Removed
131 Enable, 2048 Output
Module, COML
Module Enabled
132 Disable, 2048 Output
Module, COML
Module Disabled
133
Restart, in 5 seconds, COML User request for a module to reboot
