Chapter 6 Alarms and Events
CC Output Module Alarms and Events
322 SSU-2000 Technical Reference 12713020-003-2 Revision F.01 – January 2007
CC Output Module Alarms and Events
Table 6-24 lists the alarms and events for the Composite Clock Output module, and
includes the typical response for each alarm or event, it’s event number, and a
description or a suggested corrective action. The SNMP MIB trap is listed in the
Alarm/Event/Trap Description column. Table 6-25 lists the default parameters for the
Composite Clock Output module alarms.
Table 6-24. CC Output Module Alarm and Event Messages
Alarm/
Event/
Trap ID
Typical Alarm/Event/Trap
Response
Description/
Corrective Action
000 Alarm Deprecated, Fault Alarm not enabled
001 Module Match, Invalid Redundant configuration mismatch. Re-seat or replace module.
002 Clk-A, Lost Clock module in slot A1 is in warm-up mode or has other problems.
003 Clk-B, Lost Clock module in slot A12 is in warm-up mode or has other
problems.
004 Clk-C, Lost Reference signal is in LOS and both clocks have been removed or
are in warm-up.
005 Clk-D, Lost Only in SDU. Loss of backup clock. Check cable.
006 Clk Level, Below Clock A or B is below output module setting.
007 Clk Selected, None No clocks, no output.
008 VCXO, Lost VCXO problems, re-seat or replace module.
009 PLL, Unlocked No clocks or VCXO. Re-seat and check clocks.
010 Configuration, Fault Redundant configuration mismatch. Re-seat or replace module.
011 IntPortFlt, Active, 40000 Driver chip indicated a port fault on port 2 (4000 Hex).
012 ExtPortFlt, Active, 40000 Indication of external port fault on ports 2 and 4 (A000 Hex).
013 Hdw Config, Fault If module is installed in slot previously used by a different module
type, use the CONF xAy REMOVE command.
If problem persists, call Symmetricom Global Services
129 Install, CC Output Module Module Installed.
130 Remove, CC Output Module Module Removed.
131 Enable, CC Output Module,
COML
Module Enabled.
132 Disable, CC Output Module,
COML
Module Disabled.
133
Restart, in 5 seconds, COML
User request for a module to reboot.
134 Cannot Enable, CC Output
Module, COML
Cannot enable module due to configuration error.
